111年 - 111 高雄市市立高級中等學校聯合教師甄選試題:冷凍空調科#108257
> 申論題
11.有一冷凍設備,冷凝器之冷卻水量為 200 l/min,冷卻水入口溫度 20℃,出 口溫度 26℃,壓縮機所需功率 30 kW,求此壓縮機的冷凍能力為多少?(5%)
詳解 (共 1 筆)
小倫子
詳解 #5683753
2022/12/20
先寫來源網址 https:/...
(共 57 字,隱藏中)
前往觀看
